DA 6096 W Black Wing
Wall mounted cooker hood with energy-efficient LED lighting and light-touch switches for easy use.
Product data sheet
Construction type
| Wall mounted cooker hood | • |
Design
| Colour | Obsidian black |
Operating modes
| Type of air guide | Convertible |
| Active charcoal filter (order separately) | DKF25-1 |
User convenience
| Electronic controls | • |
| Light-touch controls | • |
| Power levels (number without Booster level) | 3 |
| Booster level | • |
Cleaning convenience
| Easy-to-clean canopy interior – CleanCover | • |
Efficiency and sustainability
| Annual energy consumption in kWh/year | 70.4 |
Filter system
| Number of dishwasher safe stainless steel grease filters | 1 |
Lighting
| LED | • |
| Number x W | 2 x 4,5 W |
| Light intensity in Lx | 380 |
| Colour temperature in K | 3.500 |
Fan
| Dual-action fan | • |
| AC motor | • |
Air throughput with max. duct diameter in extraction mode (not for external version)
| Air throughput in Level 1 (m³/h) | 200 |
| Air throughput in Level 2 (m³/h) | 300 |
| Air throughput in Level 3 (m³/h) | 400 |
| Air throughput in Booster level (m³/h) | 650 |
| Sound power in Level 1 (dB(A) re 1 pW) | 40 |
| Sound power in Level 2 (dB(A) re 1 pW) | 48 |
| Sound power in Level 3 (dB(A) re 1 pW) | 54 |
| Sound power in Booster level (dB(A) re 1 pW) | 66 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) | 25 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) | 33 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) | 39 |
| Sound pressure in Booster level (dB(A) re 20 µPa) | 51 |
Air throughput in recirculation mode
| Air throughput in Level 1 (m³/h) | 120 |
| Air throughput in Level 2 (m³/h) | 220 |
| Air throughput in Level 3 (m³/h) | 320 |
| Air throughput in Booster level (m³/h) | 520 |
| Sound power in Level 1 (dB(A) re 1 pW) | 48 |
| Sound power in Level 2 (dB(A) re 1 pW) | 55 |
| Sound power in Level 3 (dB(A) re 1 pW) | 62 |
| Sound power in Booster level (dB(A) re 1 pW) | 71 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) | 33 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) | 41 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) | 47 |
| Sound power in Booster level (dB(A) re 1 pW) | 56 |
Safety
| Safety switch-off | • |
| Single pane tempered glass | • |
Technical data
| Overall height for extraction mode and external mode cooker hoods in mm | 547 - 547 |
| Overall height for recirculation mode cooker hoods in mm | 547 - 547 |
| Canopy width in mm | 898 |
| Canopy height in mm | 547 |
| Canopy depth in mm | 523 |
| Minimum height above electric hobs in mm | 450 |
| Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm | 650 |
| Net weight in kg | 20.0 |
| Length of supply lead in m | 1.5 |
| Standard plug fitted | • |
| Hard-wired connection | • |
| Total rated load in kW | 0.21 |
| Voltage in V | 230 |
| Fuse rating in A | 10 |
| Frequency in Hz | 50 |
| Number of phases | 1 |
Installation notes
| Extraction ducting connection at top | • |
| Extraction connection at top and rear | • |
| Diameter of extraction ducting connection in mm | 150 |
Standard accessories
| Non-return flap | • |
| Adapter to reduce ducting diameter from 150 mm to 125 mm Ø | • |
